Compressed Air Receivers

Model: WBT0.3-3.0
Capacity: 300-3000L
Working pressure: 8-40 bar
Contact us Inquiry Now
Description Specifications Related Products
Contact
Description

WBT Range air receiver makes air available at a constant pressure by storing compressed air for peak demand. By avoiding undue load/unload cycles, it saves energy costs and extends the life of the compressor.

Specifications
Model Capacity Working Pressure Total Height Inside diameter Net Weight
No. L bar mm mm kg
WBT0.3 300 8 1560 550 92
10 1562 112
13 1564 156
16 1564 156
25 1568 195
30 1568 195
40 1572 262
WBT0.5 500 8 2063 600 155
10 2063 155
13 2067 157
16 2067 157
WBT0.6 600 8 1844 700 170
10 1846 196
13 1846 220
16 1846 240
25 1850 280
30 1855 372
40 1859 410
WBT1.0 1000 8 2240 800 226
10 2240 262
13 2340 271
16 2343 325
25 2351 490
30 2355 576
40 2355 582
WBT1.5 1500 8 2357 1000 338
10 2357 338
13 2359 388
16 2363 498
25 2368 630
30 2372 735
40 2380 1050
WBT2.0 2000 8 2692 1100 460
10 2692 460
13 2694 505
16 2698 660
25 2702 815
30 2706 998
40 2719 1470
WBT2.5 2500 8 2776 1200 846
10 2778 847
13 2782 850
30 2795 855
WBT3.0 3000 8 2807 1300 521
10 2809 621
13 2813 787
16 2817 1031
35 2834 1755
40 2838 2243
